How To Upload Multiple Images Using Angular 7

In this article, we will create a simple Angular 7 application in a step-by-step manner from scratch to upload multiple images using Web API, Angular 7, and SQL Server.

Introduction


In this article, I am going to explain how to upload multiple images using angular 7 and Web API. I am also creating a demo project for  better understanding. This article will help beginners who are getting started with Angular.

Prerequisites
  • Angular 7
  • Web API
  • SQL Server
  • HTML/Bootstrap

Steps required

  1. Create a database and 2 tables in SQL Server
  2. Create a Web API using ASP.NET Web API
  3. Create a new project in Angular 7
For this article, I have created a database and two tables. For creating the database, we follow the following steps.

Step 1

Let's open SSMS (SQL Server Management Studio).

How To Upload Multiple Image Using Angular 7

Step 2

Connect to the SSMS.

How To Upload Multiple Image Using Angular 7

Step 3

I have created the database using the following query.
  1. create database db_multipleimage
Step 4

I have created an Imagemaster table.
  1. CREATE TABLE [dbo].[imagemaster](
  2.     [Id] [int] IDENTITY(1,1) NOT NULL,
  3.     [ImageName] [varchar](50) NULL,
  4.     [Remark] [varchar](50) NULL,
  5.  CONSTRAINT [PK_imagemaster] PRIMARY KEY CLUSTERED
  6. (
  7.     [Id] ASC
  8. )WITH (PAD_INDEX  = OFF, STATISTICS_NORECOMPUTE  = OFF, IGNORE_DUP_KEY = OFF, ALLOW_ROW_LOCKS  = ON, ALLOW_PAGE_LOCKS  = ONON [PRIMARY]
  9. ON [PRIMARY
Now, the database looks like below.

How To Upload Multiple Image Using Angular 7

I have created a Web API using ASP.NET Web API. For creating the Web API, we need to follow the following steps.

Step 1

Open Visual Studio 2017 and go to File > New > Project.

How To Upload Multiple Image Using Angular 7

How To Upload Multiple Image Using Angular 7

Step 2

Select Web >> ASP.NET Web Application.

How To Upload Multiple Image Using Angular 7

Step 3

Then, select Web API and click OK.

How To Upload Multiple Image Using Angular 7

Step 4

Now, create a new Controller named FileUploadController.

How To Upload Multiple Image Using Angular 7

How To Upload Multiple Image Using Angular 7

Step 5

Now, import the database using Entity Framework.

How To Upload Multiple Image Using Angular 7

Step 6

Now, create a method (UploadFiles) for inserting images in the table and save images in a folder in FileUploadController.
  1. [HttpPost()]
  2.        public string UploadFiles()
  3.        {
  4.            string sPath = "";
  5.            sPath = System.Web.Hosting.HostingEnvironment.MapPath("~/image/");
  6.            var request = System.Web.HttpContext.Current.Request;
  7.            System.Web.HttpFileCollection hfc = System.Web.HttpContext.Current.Request.Files;
  8.            var remark = request["remark"].ToString();
  9.            for (int iCnt = 0; iCnt <= hfc.Count - 1; iCnt++)
  10.            {
  11.                System.Web.HttpPostedFile hpf = hfc[iCnt];
  12.                if (hpf.ContentLength > 0)
  13.                {
  14.                    string FileName = (Path.GetFileName(hpf.FileName));
  15.                    if (!File.Exists(sPath + FileName))
  16.                    {
  17.                        // SAVE THE FILES IN THE FOLDER.
  18.                        hpf.SaveAs(sPath + FileName);
  19.                        imagemaster obj = new imagemaster();
  20.                        obj.Remark = remark;
  21.                        obj.ImageName = FileName;
  22.                        wmsEN.imagemasters.Add(obj);
  23.                        wmsEN.SaveChanges();
  24.                    }
  25.                }
  26.            }
  27.            return "Upload Failed";
  28.        }
For this article, I have created an Angular project using Angular 7. For creating an Angular project, we need to follow the following steps.

Step 1

I have created a project using the following command in the Command Prompt.
  1. ng new fileupload
Step 2

Open project in Visual Studio Code using the following commands.
  1. cd fileupload
  1. code .
How To Upload Multiple Image Using Angular 7

Step 3

Now, we need to install bootstrap in our project using the following command in the terminal.
  1. npm install --save bootstrap
Step 4

After installing bootstrap, we should import bootstrap in style.css.
  1. @import '~bootstrap/dist/css/bootstrap.min.css';
Step 5

I have declared methods to upload images using the following code in App.component.ts
  1. import { Component } from '@angular/core';
  2. import { HttpClient } from '@angular/common/http';
  3.
  4. @Component({
  5.   selector: 'app-root',
  6.   templateUrl: './app.component.html',
  7.   styleUrls: ['./app.component.css']
  8. })
  9. export class AppComponent {
  10.   title = 'fileupload';
  11.   remark = '';
  12.   constructor(private httpService: HttpClient) { }
  13.   myFiles: string[] = [];
  14.
  15.   sMsg: string = '';
  16.   StudentIdUpdate: string;
  17.   ngOnInit() {}
  18.
  19.   getFileDetails(e) {
  20.     //console.log (e.target.files);
  21.     for (var i = 0; i < e.target.files.length; i++) {
  22.       this.myFiles.push(e.target.files[i]);
  23.     }
  24.   }
  25.   uploadFiles() {
  26.     const frmData = new FormData();
  27.     for (var i = 0; i < this.myFiles.length; i++) {
  28.       frmData.append("fileUpload", this.myFiles[i]);
  29.       if (i == 0) {
  30.         frmData.append("remark", this.remark);
  31.       }
  32.     }
  33.     this.httpService.post('http://localhost:50401/api/FileUpload/UploadFiles', frmData).subscribe(
  34.       data => {
  35.         // SHOW A MESSAGE RECEIVED FROM THE WEB API.
  36.         this.sMsg = data as string;
  37.         console.log(this.sMsg);
  38.       }
  39.     );
  40.   }
  41. }
Step 6

Put this code in app.component.html
  1. <!--The content below is only a placeholder and can be replaced.-->
  2. <div style="text-align:center">
  3.   <h1>
  4.     Welcome to {{ title }}!
  5.   </h1>
  7. </div>
  8.
  9. <div class="col-sm-5">
  10.   <ng-container>
  11.       <input type="file" id="file" multiple (change)="getFileDetails($event)">
  12.       <input type="text" [(ngModel)]="remark">
  13.       <button class="btn btn-primary" (click)="uploadFiles()">Upload</button>
  14.   </ng-container>
  15. </div>
Now, run the project using the following command.
  1. ng serve
How To Upload Multiple Image Using Angular 7

How To Upload Multiple Image Using Angular 7

How To Upload Multiple Image Using Angular 7

How To Upload Multiple Image Using Angular 7

Summary


In this article, I have discussed how to upload multiple images in a Web API using Angular 7. In my next article, I am going to discuss how to upload a video using Angular 7 in a Web API.
