Serialization -DeSerialization of Windows Form in C#

Serialization -DeSerialization of Windows Form in C# In which we can serilaze the window from text box control values also deserialize the it and display the deserializr values with respective thier textbox.



  1. using System;
  2. using System.Collections.Generic;
  3. using System.Linq;
  4. using System.Text;
  5. using System.Runtime.Serialization;
  6. using System.IO;
  7. using System.Runtime.Serialization.Formatters.Binary;
  8. namespace SerializationWithWINForm
  9. {
  10.  [Serializable]
  11.  public class SerializeProp
  12.  {
  13.      private int _id;
  14.      private int _number;
  15.      private string _empname = string.Empty;
  16.      private string _address = string.Empty;
  17.      public SerializeProp()
  18.      {
  19.      }
  20.      public int ID
  21.      {
  22.          get
  23.          {
  24.              return _id;
  25.          }
  26.          set
  27.          {
  28.              _id = value;
  29.          }
  30.      }
  31.      public int Number
  32.      {
  33.          get
  34.          {
  35.              return _number;
  36.          }
  37.          set
  38.          {
  39.              _number = value;
  40.          }
  41.      }
  42.      public string Address
  43.      {
  44.          get
  45.          {
  46.              return _address;
  47.          }
  48.          set
  49.          {
  50.              _address = value;
  51.          }
  52.      }
  53.      public string EmpName
  54.      {
  55.          get
  56.          {
  57.              return _empname;
  58.          }
  59.          set
  60.          {
  61.              _empname = value;
  62.          }
  63.      }
  64.
  65.  }
  66. }
  1. using System;
  2. using System.Collections.Generic;
  3. using System.ComponentModel;
  4. using System.Data;
  5. using System.Drawing;
  6. using System.Linq;
  7. using System.Text;
  8. using System.Windows.Forms;
  9. using System.IO;
  10. using System.Runtime.Serialization;
  11. using System.Runtime.Serialization.Formatters;
  12. using System.Runtime.Serialization.Formatters.Binary;
  13. namespace SerializationWithWINForm
  14. {
  15.       public partial class SerializeForm :Form
  16.       {
  17.             public SerializeForm()
  18.             {
  19.                   InitializeComponent();
  20.             }
  21.             SerializeProp objISerializeProp = new SerializeProp();
  22.             IFormatter objBinaryFormatter = new BinaryFormatter();
  23.             private string _filePath = "C:\\WinFormSerializeLog.txt";
  24.
  25.             private void button1_Click(object sender, EventArgs e)
  26.             {
  27.                   objISerializeProp.ID = Convert.ToInt32(txtID.Text);
  28.                   objISerializeProp.EmpName = txtName.Text;
  29.                   objISerializeProp.Number = Convert.ToInt32(txtNumber.Text);
  30.                   objISerializeProp.Address = txtAddress.Text;
  31.             }
  32.
  33.             private void button2_Click(object sender, EventArgs e)
  34.             {
  35.                   Stream objStream = new FileStream(_filePath,
  36.                   FileMode.Create,
  37.                   FileAccess.ReadWrite,
  38.                   FileShare.None);
  39.                   objISerializeProp.ID = objISerializeProp.ID;
  40.                   objISerializeProp.EmpName = objISerializeProp.EmpName;
  41.                   objISerializeProp.Number = objISerializeProp.Number;
  42.                   objISerializeProp.Address = objISerializeProp.Address;
  43.                   objBinaryFormatter.Serialize(objStream, objISerializeProp);
  44.                   objStream.Close();
  45.                   txtID.Text = "";
  46.                   txtName.Text = "";
  47.                   txtNumber.Text = "";
  48.                   txtAddress.Text = "";
  49.             }
  50.
  51.             private void SerializeForm_Load(object sender, EventArgs e)
  52.             {
  53.                   Stream objStreamDeSerialize = new FileStream(_filePath,
  54.                   FileMode.Open,
  55.                   FileAccess.Read,
  56.                   FileShare.Read);
  57.                   objISerializeProp = (SerializeProp)objBinaryFormatter.Deserialize(objStreamDeSerialize);
  58.                   txtID.Text = objISerializeProp.ID.ToString();
  59.                   txtName.Text = objISerializeProp.EmpName;
  60.                   txtNumber.Text = objISerializeProp.Number.ToString();
  61.                   txtAddress.Text = objISerializeProp.Address;
  62.                   objStreamDeSerialize.Close();
  63.             }
  64.
  65.             private void button3_Click(object sender, EventArgs e)
  66.             {
  67.                   txtID.Text = "";
  68.                   txtName.Text = "";
  69.                   txtNumber.Text = "";
  70.                   txtAddress.Text = "";
  71.             }
  72.       }
  73. }

  1. namespace SerializationWithWINForm
  2. {
  3.     partial class SerializeForm
  4.     {
  5.         /// <summary>
  6.         /// Required designer variable.
  7.         /// </summary>
  8.         private System.ComponentModel.IContainer components = null;
  9.         /// <summary>
  10.         /// Clean up any resources being used.
  11.         /// </summary>
  12.         /// <param name="disposing">true if managed resources should be disposed; otherwise, false.</param>
  13.         protected override void Dispose(bool disposing)
  14.         {
  15.             if (disposing && (components != null))
  16.             {
  17.                 components.Dispose();
  18.             }
  19.             base.Dispose(disposing);
  20.         }
  21.         #region Windows Form Designer generated code
  22.         /// <summary>
  23.         /// Required method for Designer support - do not modify
  24.         /// the contents of this method with the code editor.
  25.         /// </summary>
  26.         private void InitializeComponent()
  27.         {
  28.             this.button1 = new System.Windows.Forms.Button();
  29.             this.button2 = new System.Windows.Forms.Button();
  30.             this.txtID = new System.Windows.Forms.TextBox();
  31.             this.txtName = new System.Windows.Forms.TextBox();
  32.             this.txtNumber = new System.Windows.Forms.TextBox();
  33.             this.txtAddress = new System.Windows.Forms.TextBox();
  34.             this.label1 = new System.Windows.Forms.Label();
  35.             this.label2 = new System.Windows.Forms.Label();
  36.             this.label3 = new System.Windows.Forms.Label();
  37.             this.label4 = new System.Windows.Forms.Label();
  38.             this.button3 = new System.Windows.Forms.Button();
  39.             this.SuspendLayout();
  40.             //
  41.             // button1
  42.             //
  43.             this.button1.Location = new System.Drawing.Point(12, 204);
  44.             this.button1.Name = "button1";
  45.             this.button1.Size = new System.Drawing.Size(75, 23);
  46.             this.button1.TabIndex = 0;
  47.             this.button1.Text = "ok";
  48.             this.button1.UseVisualStyleBackColor = true;
  49.             this.button1.Click += new System.EventHandler(this.button1_Click);
  50.             //
  51.             // button2
  52.             //
  53.             this.button2.Location = new System.Drawing.Point(93, 204);
  54.             this.button2.Name = "button2";
  55.             this.button2.Size = new System.Drawing.Size(75, 23);
  56.             this.button2.TabIndex = 1;
  57.             this.button2.Text = "Serialize";
  58.             this.button2.UseVisualStyleBackColor = true;
  59.             this.button2.Click += new System.EventHandler(this.button2_Click);
  60.             //
  61.             // txtID
  62.             //
  63.             this.txtID.Location = new System.Drawing.Point(181, 13);
  64.             this.txtID.Name = "txtID";
  65.             this.txtID.Size = new System.Drawing.Size(100, 20);
  66.             this.txtID.TabIndex = 2;
  67.             //
  68.             // txtName
  69.             //
  70.             this.txtName.Location = new System.Drawing.Point(181, 54);
  71.             this.txtName.Name = "txtName";
  72.             this.txtName.Size = new System.Drawing.Size(100, 20);
  73.             this.txtName.TabIndex = 3;
  74.             //
  75.             // txtNumber
  76.             //
  77.             this.txtNumber.Location = new System.Drawing.Point(181, 102);
  78.             this.txtNumber.Name = "txtNumber";
  79.             this.txtNumber.Size = new System.Drawing.Size(100, 20);
  80.             this.txtNumber.TabIndex = 4;
  81.             //
  82.             // txtAddress
  83.             //
  84.             this.txtAddress.Location = new System.Drawing.Point(181, 152);
  85.             this.txtAddress.Name = "txtAddress";
  86.             this.txtAddress.Size = new System.Drawing.Size(100, 20);
  87.             this.txtAddress.TabIndex = 5;
  88.             //
  89.             // label1
  90.             //
  91.             this.label1.AutoSize = true;
  92.             this.label1.Location = new System.Drawing.Point(36, 19);
  93.             this.label1.Name = "label1";
  94.             this.label1.Size = new System.Drawing.Size(18, 13);
  95.             this.label1.TabIndex = 6;
  96.             this.label1.Text = "ID";
  97.             //
  98.             // label2
  99.             //
  100.             this.label2.AutoSize = true;
  101.             this.label2.Location = new System.Drawing.Point(39, 60);
  102.             this.label2.Name = "label2";
  103.             this.label2.Size = new System.Drawing.Size(35, 13);
  104.             this.label2.TabIndex = 7;
  105.             this.label2.Text = "Name";
  106.             //
  107.             // label3
  108.             //
  109.             this.label3.AutoSize = true;
  110.             this.label3.Location = new System.Drawing.Point(39, 108);
  111.             this.label3.Name = "label3";
  112.             this.label3.Size = new System.Drawing.Size(44, 13);
  113.             this.label3.TabIndex = 8;
  114.             this.label3.Text = "Number";
  115.             //
  116.             // label4
  117.             //
  118.             this.label4.AutoSize = true;
  119.             this.label4.Location = new System.Drawing.Point(42, 158);
  120.             this.label4.Name = "label4";
  121.             this.label4.Size = new System.Drawing.Size(45, 13);
  122.             this.label4.TabIndex = 9;
  123.             this.label4.Text = "Address";
  124.             //
  125.             // button3
  126.             //
  127.             this.button3.Location = new System.Drawing.Point(174, 204);
  128.             this.button3.Name = "button3";
  129.             this.button3.Size = new System.Drawing.Size(75, 23);
  130.             this.button3.TabIndex = 10;
  131.             this.button3.Text = "Clear";
  132.             this.button3.UseVisualStyleBackColor = true;
  133.             this.button3.Click += new System.EventHandler(this.button3_Click);
  134.             //
  135.             // SerializeForm
  136.             //
  137.             this.AutoScaleDimensions = new System.Drawing.SizeF(6F, 13F);
  138.             this.AutoScaleMode = System.Windows.Forms.AutoScaleMode.Font;
  139.             this.ClientSize = new System.Drawing.Size(292, 266);
  140.             this.Controls.Add(this.button3);
  141.             this.Controls.Add(this.label4);
  142.             this.Controls.Add(this.label3);
  143.             this.Controls.Add(this.label2);
  144.             this.Controls.Add(this.label1);
  145.             this.Controls.Add(this.txtAddress);
  146.             this.Controls.Add(this.txtNumber);
  147.             this.Controls.Add(this.txtName);
  148.             this.Controls.Add(this.txtID);
  149.             this.Controls.Add(this.button2);
  150.             this.Controls.Add(this.button1);
  151.             this.Name = "SerializeForm";
  152.             this.Text = "Form1";
  153.             this.Load += new System.EventHandler(this.SerializeForm_Load);
  154.             this.ResumeLayout(false);
  155.             this.PerformLayout();
  156.         }
  157.         #endregion
  158.         private System.Windows.Forms.Button button1;
  159.         private System.Windows.Forms.Button button2;
  160.         private System.Windows.Forms.TextBox txtID;
  161.         private System.Windows.Forms.TextBox txtName;
  162.         private System.Windows.Forms.TextBox txtNumber;
  163.         private System.Windows.Forms.TextBox txtAddress;
  164.         private System.Windows.Forms.Label label1;
  165.         private System.Windows.Forms.Label label2;
  166.         private System.Windows.Forms.Label label3;
  167.         private System.Windows.Forms.Label label4;
  168.         private System.Windows.Forms.Button button3;
  169.     }
  170. }
