Delegate Uses In C#

Multicast Delegate in C#

Delegates can be used to assign multiple objects to one delegate instance, meaning simply execute multiple methods in sequence, meaning the delegate points to more than one function. A Multicast delegate holds delegates of the same type in the list that, when called, get invoked in sequence.

myTestDel delmultiCast = new myTestDel(getName);
delmultiCast += getLocation;
delmultiCast("Abhi");

A Delegate instance can be pointed to by multiple methods using the += sign, as stated above. Basically, it adds multiple methods to one delegate instance in the invocation list.

Example

namespace Delegates
{
    public delegate void myTestDel(string Name);
    public delegate void TestMutliCast();
    public delegate int TestMutliCastint();
    class Program
    {
        static void Main(string[] args)
        {
            // Normal Method Call
            getName("By Normal Method call - Abhishek Singh ");
            // Method Call using delegates
            myTestDel del = new myTestDel(getName);
            del("By Delagete call-Abhishek singh");
            del.Invoke(" Using Invoke - Abhishek Singh ");
            del = new myTestDel(getLocation);
            del("Mumbai");
            // Mutlticast implementation with void return type
            TestMutliCast delmultiCast = new TestMutliCast(Method1);
            delmultiCast += Method2;
            delmultiCast();
            // Mutlticast implementation with void return type
            myTestDel testMulti = new myTestDel(getName);
            testMulti += getLocation;
            testMulti("Abhi");
            // Mutlticast implementation with int return type
            TestMutliCastint intMulti = new TestMutliCastint(Method3);
            intMulti += Method4;
            int i = intMulti();
            Console.WriteLine("Return Value is " + i);
            Console.ReadLine();
        }
        public static void Method1()
        {
            Console.WriteLine("Delegate 1st method called!!!!");
        }
        public static void Method2()
        {
            Console.WriteLine("Delegate 2nd method called!!!!");
        }
        public static int Method3()
        {
            Console.WriteLine("Delegate 3rd method called!!!!");
            return 3;
        }
        public static int Method4()
        {
            Console.WriteLine("Delegate 4th method called!!!!");
            return 4;
        }
        public static void getName(string name)
        {
            Console.WriteLine("My Name: " + name);
        }
        public static void getLocation(string location)
        {
            Console.WriteLine("My Loc: " + location);
        }
    }
}

Explanation

By the preceding example, I am trying to explain the implementation of Multicast delegates. You can see above that I defined three delegates with different signatures and return types. When you are using a multi-cast delegate with methods that have a void return type, the invocation of the delegate would execute the methods added in the sequence. When the return type is not void as above, in my case, it is int. Methods with Int return types are added to the delegate instance and will be executed as per the addition sequence, but the variable that is holding the return type value will have the value return from the method that is executed at the end.

In the above example, the int variable will have a value returned from the method.

Generally, a Multicast delegate is used in the observer pattern for publication and subscriber model programming.

Where to use Delegate in C#?

A Delegate can be used in various ways depending on the requirements of the project. The following are the lists of areas where a delegate can be used to provide better output and enhance the performance of the application.

1. Method Invocation (using delegate instance).
2. Event Handling using a delegate.
3. Callback and asynchronous implementation.
4. Multiple method calls using Multicast delegate.

Conclusion

A normal delegate or a Multicast delegate is a very powerful feature in C#, and it can be used by developers in various scenarios for more flexibility and a better way to improve the performance of the application.
