How To Upload And View Video Using Angular 7

In this article, you will learn how to upload and view video using Angular 7.

Introduction


In this article, I am going to explain how to upload and view Video using Angular 7 and Web API. I am also creating a demo project for better understanding. This article will help beginners who are getting started with Angular.

Prerequisites
  • Angular 7
  • Web API
  • SQL Server
  • HTML/Bootstrap

Steps required

  1. Create a database and 2 tables in SQL Server
  2. Create a Web API using ASP.NET Web API
  3. Create a new project in Angular 7
For this article, I have created a database and two tables. For creating the database, we follow the following steps.

How To Upload And View Video Using Angular 7

Step 2

Connect to the SSMS.

How To Upload And View Video Using Angular 7

Step 3

I have created the database using the following query.

create database db_video

Step 4

I have created a Videomaster table.
  1. CREATE TABLE [dbo].[VideoMaster](
  2.     [Id] [int] IDENTITY(1,1) NOT NULL,
  3.     [Videos] [varchar](50) NULL,
  4.  CONSTRAINT [PK_VideoMaster] PRIMARY KEY CLUSTERED
  5. (
  6.     [Id] ASC
  7. )WITH (PAD_INDEX  = OFF, STATISTICS_NORECOMPUTE  = OFF, IGNORE_DUP_KEY = OFF, ALLOW_ROW_LOCKS  = ON, ALLOW_PAGE_LOCKS  = ONON [PRIMARY]
  8. ON [PRIMARY]
Now, the database looks like below.

How To Upload And View Video Using Angular 7

I have created a Web API using ASP.NET Web API. For creating the Web API, we need to follow the following steps.

Step 1

Open Visual Studio 2017 and go to File > New > Project.

How To Upload And View Video Using Angular 7

How To Upload And View Video Using Angular 7

Step 2

Select Web >> ASP.NET Web Application.

How To Upload And View Video Using Angular 7

Step 3

Then, select Web API and click OK.

How To Upload And View Video Using Angular 7

Step 4

Now, create a new Controller named FileUploadController.

How To Upload And View Video Using Angular 7

How To Upload And View Video Using Angular 7

Step 5

Now, import the database using Entity Framework.

How To Upload And View Video Using Angular 7

Step 6

Now, create a method (UploadFiles) for inserting images in the table and save images in a folder in FileUploadController.
  1. using MvcApplication1.Models;
  2. using System;
  3. using System.Collections.Generic;
  4. using System.IO;
  5. using System.Linq;
  6. using System.Net;
  7. using System.Net.Http;
  8. using System.Web;
  9. using System.Web.Http;
  10.
  11. namespace MvcApplication1.Controllers
  12. {
  13.     public class FileUploadController : ApiController
  14.     {
  15.         db_videoEntities1 wmsEN = new db_videoEntities1();
  16.         [HttpPost()]
  17.         public HttpResponseMessage UploadFiles()
  18.         {
  19.             var httpRequest = HttpContext.Current.Request;
  20.             //Upload Image
  21.             System.Web.HttpFileCollection hfc = System.Web.HttpContext.Current.Request.Files;
  22.             try
  23.             {
  24.                 for (int iCnt = 0; iCnt <= hfc.Count - 1; iCnt++)
  25.                 {
  26.                     System.Web.HttpPostedFile hpf = hfc[iCnt];
  27.                     if (hpf.ContentLength > 0)
  28.                     {
  29.                         var filename = (Path.GetFileName(hpf.FileName));
  30.                         var filePath = HttpContext.Current.Server.MapPath("~/Vedios/" + filename);
  31.                         hpf.SaveAs(filePath);
  32.                         VideoMaster obj = new VideoMaster();
  33.                         obj.Videos = "http://localhost:50401/Vedios/"+filename;
  34.                         wmsEN.VideoMasters.Add(obj);
  35.                         wmsEN.SaveChanges();
  36.                     }
  37.                 }
  38.             }
  39.             catch (Exception ex)
  40.             { }
  41.             return Request.CreateResponse(HttpStatusCode.Created);
  42.         }
  43.
  44.        [HttpPost]
  45.         public object Vedios()
  46.         {
  47.             return wmsEN.VideoMasters;
  48.         }
  49.     }
  50. }
For this article, I have created an Angular project using Angular 7. For creating an Angular project, we need to follow the following steps.

Step 1

I have created a project using the following command in the Command Prompt.
  1. ng new fileupload
Step 2

Open project in Visual Studio Code using the following commands.
  1. cd fileupload
  1. code .
How To Upload And View Video Using Angular 7

Step 3

Now, we need to install Bootstrap in our project using the following command in the terminal.
  1. npm install --save bootstrap
Step 4

After installing Bootstrap, we should import Bootstrap in style.css.
  1. @import '~bootstrap/dist/css/bootstrap.min.css';
Step 5

I have create a class:
  1. export class VideoMaster
  2. {
  3.      int:number;
  4.      Videos:string;
  5. }
Step 6

I have declared methods to upload images using the following code in App.component.ts
  1. import { Component, ViewChild, ElementRef } from '@angular/core';
  2. import { HttpClient } from '@angular/common/http';
  3. import { VideoMaster } from './VideoMaster';
  4. import { Observable } from 'rxjs';
  5.
  6. @Component({
  7.   selector: 'app-root',
  8.   templateUrl: './app.component.html',
  9.   styleUrls: ['./app.component.css']
  10. })
  11. export class AppComponent {
  12.   title = 'fileupload';
  13.   remark = '';
  14.   constructor(private httpService: HttpClient) { }
  15.   myFiles: string[] = [];
  16.   myVideos: Observable<VideoMaster[]>;
  17.
  18.   @ViewChild('videoPlayer') videoplayer: ElementRef;
  19.
  20.   toggleVideo(event: any) {
  21.       this.videoplayer.nativeElement.play();
  22.   }
  23.   getvideos() {
  24.     debugger;
  25.    this.myVideos= this.VediosList();
  26.   }
  27.
  28.   VediosList(): Observable<VideoMaster[]> {
  29.     return this.httpService.get<VideoMaster[]>('http://localhost:50401/api/FileUpload/Vedios');
  30.   }
  31.
  32.   sMsg: string = '';
  33.   StudentIdUpdate: string;
  34.   ngOnInit() {
  35.     this. getvideos();
  36.   }
  37.
  38.   getFileDetails(e) {
  39.     //console.log (e.target.files);
  40.     for (var i = 0; i < e.target.files.length; i++) {
  41.       this.myFiles.push(e.target.files[i]);
  42.     }
  43.   }
  44.   uploadFiles() {
  45.     const frmData = new FormData();
  46.     for (var i = 0; i < this.myFiles.length; i++) {
  47.       frmData.append("fileUpload"this.myFiles[i]);
  48.     }
  49.     this.httpService.post('http://localhost:50401/api/FileUpload/UploadFiles', frmData).subscribe(
  50.       data => {
  51.         // SHOW A MESSAGE RECEIVED FROM THE WEB API.
  52.         this.sMsg = data as string;
  53.         console.log(this.sMsg);
  54.       }
  55.     );
  56.   }
  57.
  58. }
Step 7

Put this code in app.component.html
  1. <!--The content below is only a placeholder and can be replaced.-->
  2. <div style="text-align:center">
  3.   <h1>
  4.     Welcome to {{ title }}!
  5.   </h1>
  7. </div>
  8.
  9. <div class="col-sm-10">
  10.   <ng-container>
  11.       <input type="file" id="file" multiple (change)="getFileDetails($event)">
  12.       <button class="btn btn-primary" (click)="uploadFiles()">Upload</button>
  13.   </ng-container>
  14. </div>
  15. <div class="col-sm-10" *ngFor="let Video of myVideos | async; let i=index">
  16.   <video width="270" height="220"   controls disabled="true"  (click)="toggleVideo()" #videoPlayer>
  17.     <source [src]="Video.Videos" type="video/mp4">
  18.   </video>
  19. </div>
 Now, run the project using the following command.
  1. ng serve
How To Upload And View Video Using Angular 7

How To Upload And View Video Using Angular 7

How To Upload And View Video Using Angular 7

How To Upload And View Video Using Angular 7


Summary


In this article, I have discussed how to upload multiple images in a Web API using Angular 7. In my next article, I am going to discuss Reactive Forms Validation using Angular 7.
