UPS and FedEx API Integration for Shipping in ASP.NET Core + Angular

In today’s e-commerce world, shipping is very important. Customers expect fast and accurate delivery. UPS and FedEx are two popular shipping carriers. If you are building an ERP, e-commerce, or shipping system, integrating their APIs helps you create shipping labels, track packages, and calculate shipping cost automatically.

In this guide, I will show you how to integrate UPS and FedEx APIs using ASP.NET Core for the backend and Angular for the frontend, in a simple way.

ups1

1. Prerequisites

Before starting, make sure you have:

  • ASP.NET Core 5 or above (Backend)

  • Angular 17 (Frontend)

  • SQL Server (Database, optional)

  • UPS and FedEx developer accounts

  • Basic knowledge of C# and Angular

2. Create Developer Account

UPS:

  1. Go to UPS Developer Portal.

  2. Sign up for a free account.

  3. Request API access keys. You will get:

    • Access Key

    • Username

    • Password

  4. Note the API endpoints (sandbox and production).

FedEx:

  1. Go to FedEx Developer Portal.

  2. Sign up for a free developer account.

  3. Request API credentials:

    • Key

    • Password

    • Account Number

    • Meter Number

  4. Note FedEx sandbox and production URLs.

3. Backend Setup: ASP.NET Core

We will create APIs in ASP.NET Core to talk to UPS and FedEx.

Step 1. Create ASP.NET Core Project

dotnet new webapi -n ShippingAPI
cd ShippingAPI

Step 2. Add Required Packages

Install HttpClientFactory and Newtonsoft.Json for calling API and parsing response:

dotnet add package Microsoft.Extensions.Http
dotnet add package Newtonsoft.Json

Step 3. Create Model for Shipping Request

Create ShippingRequest.cs:

public class ShippingRequest
{
    public string ServiceType { get; set; }  // e.g. "Ground", "Express"
    public string SenderAddress { get; set; }
    public string ReceiverAddress { get; set; }
    public decimal PackageWeight { get; set; }
    public string PackageDimensions { get; set; }
}

Step 4. Create UPS Service

Create UpsService.cs:

using System.Net.Http;
using System.Text;
using Newtonsoft.Json;

public class UpsService
{
    private readonly HttpClient _httpClient;

    public UpsService(HttpClient httpClient)
    {
        _httpClient = httpClient;
    }

    public async Task<string> CreateShipmentAsync(ShippingRequest request)
    {
        var upsRequest = new
        {
            Shipment = new
            {
                Shipper = new { Address = request.SenderAddress },
                ShipTo = new { Address = request.ReceiverAddress },
                Package = new { Weight = request.PackageWeight }
            }
        };

        var json = JsonConvert.SerializeObject(upsRequest);
        var content = new StringContent(json, Encoding.UTF8, "application/json");

        var response = await _httpClient.PostAsync("https://onlinetools.ups.com/rest/Ship", content);
        return await response.Content.ReadAsStringAsync();
    }
}

Step 5. Create FedEx Service

Create FedExService.cs:

using System.Net.Http;
using System.Text;
using Newtonsoft.Json;

public class FedExService
{
    private readonly HttpClient _httpClient;

    public FedExService(HttpClient httpClient)
    {
        _httpClient = httpClient;
    }

    public async Task<string> CreateShipmentAsync(ShippingRequest request)
    {
        var fedExRequest = new
        {
            RequestedShipment = new
            {
                ShipTimestamp = DateTime.UtcNow,
                Shipper = new { Address = request.SenderAddress },
                Recipient = new { Address = request.ReceiverAddress },
                PackageCount = 1,
                PackageWeight = request.PackageWeight
            }
        };

        var json = JsonConvert.SerializeObject(fedExRequest);
        var content = new StringContent(json, Encoding.UTF8, "application/json");

        var response = await _httpClient.PostAsync("https://apis-sandbox.fedex.com/ship/v1/shipments", content);
        return await response.Content.ReadAsStringAsync();
    }
}

Step 6. Register Services in Program.cs

builder.Services.AddHttpClient<UpsService>();
builder.Services.AddHttpClient<FedExService>();

Step 7. Create Shipping Controller

[ApiController]
[Route("api/[controller]")]
public class ShippingController : ControllerBase
{
    private readonly UpsService _upsService;
    private readonly FedExService _fedExService;

    public ShippingController(UpsService upsService, FedExService fedExService)
    {
        _upsService = upsService;
        _fedExService = fedExService;
    }

    [HttpPost("ups")]
    public async Task<IActionResult> CreateUpsShipment([FromBody] ShippingRequest request)
    {
        var result = await _upsService.CreateShipmentAsync(request);
        return Ok(result);
    }

    [HttpPost("fedex")]
    public async Task<IActionResult> CreateFedExShipment([FromBody] ShippingRequest request)
    {
        var result = await _fedExService.CreateShipmentAsync(request);
        return Ok(result);
    }
}

4. Frontend Setup: Angular

Step 1. Create Angular Service

ng generate service shipping

shipping.service.ts:

import { HttpClient } from '@angular/common/http';
import { Injectable } from '@angular/core';

@Injectable({ providedIn: 'root' })
export class ShippingService {
  private baseUrl = 'https://localhost:5001/api/shipping';

  constructor(private http: HttpClient) {}

  createUpsShipment(shippingData: any) {
    return this.http.post(`${this.baseUrl}/ups`, shippingData);
  }

  createFedExShipment(shippingData: any) {
    return this.http.post(`${this.baseUrl}/fedex`, shippingData);
  }
}

Step 2. Create an Angular Component

ng generate component shipping

shipping.component.ts:

import { Component } from '@angular/core';
import { ShippingService } from './shipping.service';

@Component({
  selector: 'app-shipping',
  templateUrl: './shipping.component.html'
})
export class ShippingComponent {
  shippingData = {
    serviceType: 'Ground',
    senderAddress: 'Sender Address Here',
    receiverAddress: 'Receiver Address Here',
    packageWeight: 2
  };

  constructor(private shippingService: ShippingService) {}

  createUpsShipment() {
    this.shippingService.createUpsShipment(this.shippingData).subscribe(res => {
      console.log('UPS Response:', res);
    });
  }

  createFedExShipment() {
    this.shippingService.createFedExShipment(this.shippingData).subscribe(res => {
      console.log('FedEx Response:', res);
    });
  }
}

shipping.component.html:

<h3>Create Shipment</h3>
<button (click)="createUpsShipment()">Create UPS Shipment</button>
<button (click)="createFedExShipment()">Create FedEx Shipment</button>

5. Test Your Integration

  1. Run ASP.NET Core backend: dotnet run

  2. Run Angular frontend: ng serve

  3. Open the Angular app in the browser and click Create UPS Shipment or Create FedEx Shipment.

  4. Check the console for response and verify the shipping label or tracking number returned by UPS/FedEx.

6. Notes and Tips

  • Always test first in sandbox environment.

  • Keep API keys and passwords secure (never commit to Git).

  • For production, switch to production API URLs.

  • You can extend this integration to track shipments, calculate rates, and print labels.

Conclusion

Integrating UPS and FedEx APIs in your system using ASP.NET Core and Angular helps automate shipping, save time, and reduce errors. Once integrated, you can easily create shipments, track them, and manage shipping cost dynamically.

By following this guide step by step, even beginners can implement shipping API integration without much trouble.
