Which ORM toll use to create this structure

arvind haritus

12y1.9kSoftware Architecture/Engineering

Hello,

I have a existing project which have following structure. I want to find out two things

Which ORM tool use to create this?
Which Design pattern this structure following?

Please help me

4 Replies

Know the answer? Post it — somebody with the same question will find it here.

rahul ahuja12y ago
Hi ,
If am not wrong then this project uses design pattern Repository and Unit of Work.

Your project architecture looks like below
Common
Domain
Repository
Web(UI)

1)Common :-
I)This is class library project which holds common functions which are used accross several logical layers.
II)E.g Security, Validation function, Convertion function,logging
III)This layer not only used by in same application but also use can use with other project.

2)Domain:-
I)This layer is deal with Data base and its object
II)Class for the DTO, DAL

3)Repository:-
I) This layer used by Web(UI) Layer
II)We should have a respository for every single Entity
III)In you application under Domain Class Named "Category" will have repository "CategoryRepository".
IV)This layer act as Centerlize common data access functionality.

4)Web(UI):-
I)This layer is use for presentation layer
II)This layer gets data from Repository layer

I hope this will help you
Ramesh Maruthi12y ago
http://www.asp.net/mvc/tutorials/getting-started-with-ef-using-mvc once look at this dude...
arvind haritus12y ago
This is a sample application that I have.

I am very new to MVC and want to work on it.
I want to create a simple project can anyone please guide me which project architecture I should use?

Do I need to go with any ORM?

-Arvind
Ramesh Maruthi12y ago
I don't know exactly which design pattern it is, but I can say only one thing its MVC project which can be seen there, The ORM TOOL they are using definitely Entity Framework

1 st Layer is( Entity Framework)
2 nd layer is some kind of services
3rd layer MVC
