Business Entity And Data Access Layer In MVC

Step 4: Create Data Access Layer (DL).

• Right click on Solution Explorer and add Class Library project and name it MVC_DataAccessLayer.
• Then change the class name as DL_Employee.
• Add the BE project ref to DL.
• Copy and paste the following code in your BE_Employee.

  1. using MVC_BusinessEntities;
  2. using System;
  3. using System.Collections.Generic;
  4. using System.Configuration;
  5. using System.Data;
  6. using System.Data.SqlClient;
  7. namespace MVC_DataAccessLayer
  8. {
  9. public class DL_Employee
  10. {
  11. public IEnumerable < BE_Employee > Employees
  12. {
  13. get
  14. {
  15. string connectionString = ConfigurationManager.ConnectionStrings["conStr"].ConnectionString;
  16. List < BE_Employee > employees = new List < BE_Employee > ();
  17. using(SqlConnection con = new SqlConnection(connectionString))
  18. {
  19. SqlCommand cmd = new SqlCommand("USP_GetAllEmployees", con);
  20. cmd.CommandType = CommandType.StoredProcedure;
  21. //cmd.Parameters.AddWithValue("@DeptId", null);
  22. con.Open();
  23. SqlDataReader rdr = cmd.ExecuteReader();
  24. while (rdr.Read())
  25. {
  26. BE_Employee employee = new BE_Employee();
  27. employee.ID = Convert.ToInt32(rdr["Id"]);
  28. employee.Name = rdr["Name"].ToString();
  29. employee.Gender = rdr["Gender"].ToString();
  30. employee.Salary = Convert.ToInt32(rdr["Salary"]);
  31. employee.DeptId = Convert.ToInt32(rdr["DeptId"]);
  32. employees.Add(employee);
  33. }
  34. }
  35. return employees;
  36. }
  37. }
  38. }
  39. }

Step 5: Add references.

• Build the Dl project.
• And the add the BE and DL references to MVC Project.

Step 6: Add a Controller.

Right click on controller folder, click on Add -> Controller and name it EmployeeController. Then click on Add.



Copy and paste the following code in your EmployeeController.
